0.8mm Nicr3020 Wire Isa-Chrom30 Wire Ni30cr20 Resistance Wire for Sealer

Name: 0.8mm Nicr3020 Wire Isa-Chrom30 Wire Ni30cr20 Resistance Wire for Sealer
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: NiCr 30/20
Price: 22.00 USD
Availability: InStock

Rincian Produk

Tempat asal: Shanghai

Nama merek: Tankii

Sertifikasi: DIN, ASTM, JIS

Nomor model: NiCr 30/20

Ketentuan Pembayaran & Pengiriman

Kuantitas min Order: 20kg

Harga: 15-30$

Kemasan rincian: spool, coil, atau sebagai kebutuhan klien

Waktu pengiriman: 25 hari

Syarat-syarat pembayaran: L/C, D/A, D/P, T/T, Western Union

Menyediakan kemampuan: 1000T/bulan

Dapatkan Harga Terbaik

Hubungi sekarang

Spesifikasi

Deskripsi

Spesifikasi

Menyoroti:

Aplikasi:	Bidang kimia, kedirgantaraan, listrik, dll	Bahan konduktor:	Nikel, Kromium
Jenis:	Tegangan rendah	Bahan isolasi:	PVC
Jaket:	Karet	Warna:	Sebagaimana diperlukan
Isolasi:	Karet silikon	Tegangan Dinilai:	300/500V
Jenis konduktor:	padat	Standar:	IEC

Aplikasi:	Bidang kimia, kedirgantaraan, listrik, dll
Bahan konduktor:	Nikel, Kromium
Jenis:	Tegangan rendah
Bahan isolasi:	PVC
Jaket:	Karet
Warna:	Sebagaimana diperlukan
Isolasi:	Karet silikon
Tegangan Dinilai:	300/500V
Jenis konduktor:	padat
Standar:	IEC

Deskripsi

0.8mm Nicr3020 Wire Isa-Chrom30 Wire Ni30cr20 Resistance Wire for Sealer

0.8mm Nicr3020 Wire Isa-Chrom30 Wire Ni30cr20 Resistance Wire for Sealer

Nicr3020
(Common Name: Ni30Cr20,Nikrothal 30, N3, HAI-NiCr 30, Resistohm 30,30-20 Ni-Cr,Nikrothal 3.)

Nicr3020 is a nickel-chromium alloy (NiCr alloy) characterized by High resistivity, good oxidation resistance,very good form stability,good ductility and excellent weldability. It is suitable for use at temperatures up to 1100°C.
Typical applications for NiCrC3020 are used in olid hot plates,open coil heaters in HVAC systems,night-storage heaters,convection heaters,heavy duty rheostats and fan heaters. And also used for heating cables and rope heaters in defrosting and de-icing elements,electric blankets and pads, car seats,baseboard heaters,floor heaters and resistors.

Normal composition%

C	P	S	Mn	Si	Cr	Ni	Al	Fe	Other
Max
0.08	0.02	0.015	1.00	1.0~2.0	18.0~21.0	30.0~34.0	-	Bal.	-

Typical Mechanical properties(1.0mm)

Yield strength	Tensile Strength	Elongation
Mpa	Mpa	%
340	675	35

Typical Physical properties

Density (g/cm3)	7.9
Electrical resistivity at 20ºC(Ωmm2/m)	1.04
Conductivity coefficient at 20ºC (WmK)	13

Coefficient of thermal expansion
Temperature	Coefficient of Thermal Expansion x10-6/ºC
20 ºC- 1000ºC	19

Specific heat capacity
Temperature	20ºC
J/gK	0.50

Melting point (ºC)	1390
Max continuous operating temperature in air (ºC)	1100
Magnetic properties	non-magnetic

Temperature Factors Of Electrical Resistivity

20ºC	100ºC	200ºC	300ºC	400ºC	500ºC	600ºC
1	1.023	1.052	1.079	1.103	1.125	1.141
700ºC	800ºC	900ºC	1000ºC	1100ºC	1200ºC	1300ºC
1.158	1.173	1.187	1.201	1.214	1.226	-

Style of supply

Wire	D=0.03mm~8mm
NiCrC3020	Ribbon	W=0.4~40	T=0.03~2.9mm
NiCrC3020	Strip	W=8~250mm	T=0.1~3.0
NiCrC3020	Foil	W=6~120mm	T=0.003~0.1
NiCrC3020	Bar	Dia=8~100mm	L=50~1000

0.8mm Nicr3020 Wire Isa-Chrom30 Wire Ni30cr20 Resistance Wire for Sealer 0
