Platinum Iridium Tube PtIr Alloy Medical Grade with OD 0.15mm-5.0mm and WT 0.01mm-2mm in PT90IR10

Name: Platinum Iridium Tube PtIr Alloy Medical Grade with OD 0.15mm-5.0mm and WT 0.01mm-2mm in PT90IR10
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: Pipa Pt-Ir
Price: 499.05 USD
Availability: InStock

Rincian Produk

Tempat asal: Shanghai, Tiongkok

Nama merek: TANKII

Sertifikasi: ISO9001

Nomor model: Pipa Pt-Ir

Ketentuan Pembayaran & Pengiriman

Kuantitas min Order: 200 buah

Harga: dapat dinegosiasikan

Kemasan rincian: kotak kayu

Waktu pengiriman: 7-20 hari

Syarat-syarat pembayaran: L/C, T/T, Western Union

Menyediakan kemampuan: 10 ton per bulan

Dapatkan Harga Terbaik

Hubungi sekarang

Spesifikasi

Deskripsi

Spesifikasi

Menyoroti:
                                                                                                                                                                                                                                                                                                                                                                                                      Platinum Iridium medical tube, PtIr alloy precision tubing, PT90IR10 medical alloy tube


Bahan:	tabung platina iridium	Mencicipi:	menerima pesanan kecil
OD:	Minimal 0,20mm.	WT:	menit 0,01 mm.
Permukaan:	Permukaan terang	Kode HS:	7115909000

Bahan:	tabung platina iridium
Mencicipi:	menerima pesanan kecil
OD:	Minimal 0,20mm.
WT:	menit 0,01 mm.
Permukaan:	Permukaan terang
Kode HS:	7115909000

Deskripsi

Platinum Iridium Tube PtIr Alloy Medical Grade with OD 0.15mm-5.0mm and WT 0.01mm-2mm in PT90IR10

Product Overview

An almost endless variety of platinum alloys can be produced based upon individual customer needs. Alloys are generally produced by vacuum arc melting or induction melting. While common alloys used in the jewelry industry are malleable, less common alloys can be very brittle and unworkable.
Platinum-iridium
Material Percentages
Pt-Ir wire(0.2-3mm) 90/10, 85/15, 80/20,75/25
Pt-Ir Rod(3-10mm) 90/10, 85/15, 80/20,75/25
Pt-Ir Foil(0.1-0.2mm) 90/10, 85/15, 80/20,75/25
Pt-Ir sheet(0.25-2mm) 90/10, 85/15, 80/20,75/25

Pt-Ir tube(0.02-5mm) 90/10, 85/15, 80/20,75/25
Other alloy percentages are available on request. Wire is spooled and sold by the foot or meter; rod is sold by the inch or
foot;foil and sheet are sold by square inch or foot. Call or email for additional diameters, forms or custom sizes.

Material	Melting point °C	Density g/cm
Pure Pt --- Pt(99.99%)	1772	21.45
Pure Rh--- Rh(99.99%)	1963	12.44
Pt-Rh5%	1830	20.70
Pt-Rh10%	1860	19.80
Pt-Rh20%	1905	18.80
Pure Ir --- Ir(99.99%)	2410	22.42
Pt-Ir5%	1790	21.49
Pt-Ir10%	1800	21.53
Pt-Ir20%	1840	21.81
Pt-Ir25%	1840	21.70
Pt-Ir30%	1850	22.15

OD
mm

W.T. /mm

≥0.015

≥0.02

≥0.05

≥0.10

≥0.20

≥0.30

≥0.40

≥0.50

≥0.60

≥0.70

≥0.80

≥0.90

≥1.00

≥1.5

≥0.3

≥0.5

≥1.0

≥1.5

≥2.0

≥3.0

≥4.0

≥5.0

≥6.0

≥7.0

≥8.0

≥9.0

≥10.0

≥15.0

≥20.0
